Product Overview
Eddy current separation is one of the most effective technologies for recovering non‑ferrous metals from mixed materials. It offers excellent separation results, strong adaptability, lightweight construction, and highly efficient metal recovery. Widely used in electronic waste recycling lines, these separators extract valuable metals such as copper and aluminum from mixed waste streams.
Eddy current separators play a vital role in environmental protection and resource recovery, especially in the non‑ferrous metal recycling industry.
Application Fields
Household appliance scrap
Automotive scrap and shredder residue
Power cable and circuit board scrap
Mixed metals and incineration slag
PET bottle flake purification
Glass recycling
Municipal solid waste (MSW) incineration slag sorting
Waste aluminum recycling systems
Key Features
-
Eddy Current Sorting Technology
A high‑speed magnetic rotor induces eddy currents within conductive metals, generating a repulsive force that separates them from non‑metallic materials. Plastics, glass, and other dry recyclables fall freely, ensuring clean separation.
-
Efficient Non‑Ferrous Metal Recovery
Recovers aluminum, copper, and other non‑ferrous metals from mixed waste streams, improving recycling yields and resource utilization.
-
Versatility Across Industries
Electronics recycling
Construction and demolition processing
Wood recycling
Incineration ash treatment
Plastics recycling
MRFs (Material Recovery Facilities)
-
Certified Quality
Desen Mining processing equipment is certified with GB/9001‑ISO9001:2000, ISO14001:2004, and CE certifications.
Product Benefits
Improves recycling efficiency
Enhances valuable metal recovery
Excellent sorting accuracy up to 98%
Reduces labor and increases output value
Durable construction and low maintenance
Multi‑stage sorting for high‑purity metal output
Stable, safe, and easy one‑button operation
Technical Specifications
| Model | ECS65P | ECS80P | ECS100P | ECS120P | ECS150P | ECS180P |
|---|---|---|---|---|---|---|
| Magnetic Roller Diameter (mm) | 500 | 500 | 500 | 500 | 500 | 500 |
| Magnetic Roller Speed (rpm) | 0–3100 | 0–3100 | 0–3000 | 0–3000 | 0–3000 | 0–3000 |
| Belt Width (mm) | 650 | 800 | 1000 | 1200 | 1500 | 1700 |
| Belt Speed (m/s) | 0–2 | 0–2 | 0–2 | 0–2 | 0–2 | 0–2 |
| Power (kW) | 4.0 + 1.1 | 4.0 + 1.5 | 5.5 + 1.5 | 5.5 + 2.2 | 5.5 + 2.2 | 5.5 + 3.0 |
| Weight (kg) | 2000 | 2500 | 2900 | 3600 | 3800 | 3900 |
| Dimensions (mm) | 3670×1650×1285 | 3670×2000×1285 | 3670×2300×1285 | 4160×2400×1285 | 4160×2600×1285 | 4160×2600×1285 |
