【Application】
①small ore size(<50mm)
②0.5-3g/t low grade gold ore
③tailings after flotation process
【Features】
①Simple process
②Easy to operate
③Less equipment
④Less power consumption
⑤Less investment and quick effect. The foundation construction cost is about 25% of the CIL/CIP plant
⑥Low production cost, which is about 30-40% of the CIL/CIP process
Benefit: the recovery rate of gold can reach 80-90%.
【Tailing treatment】
The leaching solution of gold ore heap leaching is highly toxic cyanide containing solution. The cyanide concentration in the leaching solution can reach to 1000 mg / L as the highest, which is generally maintained at 300-800 mg / L. The final concentration will also reach 200 mg / L, and the lowest concentration will also reach tens of mg / L.This kind of solution can't be discharged directly, it can be discharged after treating to reach the national standard.
「The methods of treating cyanide containing tailing wastewater」
①Alkaline cyanidation (Advantage: the reagent is easy to buy, the operation is simple, and the reaction is complete. Disadvantages: expensive cyanide cannot be recovered)
②Acidification (acidification-volatilization-alkali absorption)
It is suitable for wastewater with high concentration of cyanide and large amount of water. Disadvantages: It is difficult to reach the emission standard in one step, and other methods are needed too.
③Natural purification (the main process is as follows: Wastewater solid adsorption, sedimentation, aeration volatilization, water dilution, natural degradation)
No investment, no operation cost, suitable for the mine of having large capacity tailings pond, long relative purification time, sufficient dilution water amount, good aeration conditions and strong biological action.
④Incology: At room temperature, adjust the pH value to ph6-10 with lime milk, and use a small amount of copper sulfate as catalyst for treatment by sulfur dioxide and air;
The cost of chemicals is low, and the operation is safe and reliable.
⑤Cycle method: Cycle spray, cyanide solution return all, zero discharge. This is the most recommended way, which has both economic value and environmental benefits.
⑥Others
★Sample testing★
①Quantity:About 20-30kgs
②Ore sample:Average content(not high not low, only representive)
★Technique service★
We will dispatch the senior engineer to the ore site for guiding & training & teaching. After the miner gets first batch gold product and understand the whole process, the engineer can back to China.
Advatange:
After the engineer back to China, our company will keep offering you the technique consulting for lifelong.
※Cases
100tons Gold Pit Leaching plant(←Click on) Large Heap Leaching Plant(←Click on)
10MT Environmental Type Gold Leaching Chemicals Export To India(←Click on)
