In leaching systerm, there are many different products in our factory, which are including Gold CIL/CIP plant, Leaching chemicals, Heap/vat leaching, container type gold cil/cip plant etc.
Considering the primary investment cost and quick profits return, many gold miners prefer to container type gold CIL/CIP plant.
※Cases
10TPD Mobile Gold CIL Plant Export to Niger(←Click on) 10TPD Mobile Gold CIL Plant Export to Nicaragua(←Click on)
【Basic process】
Ore pulp impurity removal-leaching and adsorption-desorption electrolysis-smelting
①This is the integrated container cyanidation,which is completely mini gold cyanide plant which suits for small scale miners with high gold recovery rate expectation.
②It integrates the whole process of cyanidation gold extraction into the container, which can not only realize the extraction of gold, but also move freely in the mining area according to the terrain and mining requirements.
③The integrated cyanidation container does not need installation and debugging, and can be put into use directly after arriving the mine sites.
【Equipment introduction】
①Production capacity: 10-20 tons / 24 hours
②Equipment size: 12500mm * 2400mm * 3900mm (* 2)
③Using conditions: the ambient temperature is not more than + 40 ℃, not less than - 10 ℃, with good ventilation and flat ground
④Power requirements: three phase 380V, 50Hz
⑤The total installed power: 60kW
【Features】
This 10TPD Mobile Gold CIL Plant with one ball mill, the output size will be 200mesh of 70-80%, the recovery rate will be around 80-95%.
①It's a pilot scale test plant for serious miners who have high recovery expectation.
②High gold recovery, 90% min.
③Low investment cost.
④Cost return within one month production (Base raw gold grade)
⑤Make you clearly before you built a large CIP/CIL plant;Best choice to max reduce your CIP/CIL plant investment risk.
⑥All machines will be installed well in three containers before shipment;(including water systems and electric control system)
⑦Operate all machines into production directly when open containers.
【Invest & Output】
This mini cip/cil plant is a pilot scale test which is best using and low investment cost. We estimate you can get cost return within TWO month production
For example:
1. Feed ore: Gold 3G / ton
2. Recovery : 90%
3. Operation cost: About USD20 per day.- (including water, electricity, labor etc.)
4. Capacity : 10tpd.
5. 1oz=28.349523148774(g)=USD1780.75(2021-04-20 Gold price)
1g gold price =USD62.8.
10ton*3g/ton*90% *USD62.8-usd20=USD1675.6
So, one day profit will be USD1675.6
One month: USD 50268.-
For serious miner, it's the best choice to max reduce your invest risk , and make you clearly before you built a large CIP/CIL processing plant also..
【Equipment details】
All machines including water system and electric control system will be installed well in three containers before shipment.
①One is gold crushing & grinding container.
It includes jaw crusher, hammer crusher, ball mill, conveyor belt, hydrocyclone, screen, mercury plate to extract gold in amalagamation and so on.
②Another is gold leaching container.
We will get gold max extraction in this container. Thickener is for adjusting the ore pulp concentration, then the ore pulp is mixing with chemical agent in mixing tank, which will be pumped to leaching tanks for leaching. Carbon is loaded in the carbon lifter in the leaching tanks to adsorb gold.
③The third one container is for desorption electrolysis & gold smelting.
After the carbon is saturated with gold, take out the carbon lifter for desorption electrolytic, separating gold from carbon. Then, we get the gold mud for smelting. At last, we get the gold ingot.
You can operate all machines into production directly when open containers.
From gold ore to gold ingot evolution, we will complete the transition in this 10TPD Mobile Gold CIL Plant.
★Sample testing★
①Quantity:About 20-30kgs
②Ore sample:Average content(not high not low, only representive)
★Technique service★
We will dispatch the senior engineer to the ore site for guiding & training & teaching. After the miner gets first batch gold product and understand the whole process, the engineer can back to China.
Advatange:
After the engineer back to China, our company will keep offering you the technique consulting for lifelong.
